Omron R88D-KN series User Manual

2-27
2 Models and External Dimensions
G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
2-4 External and Mounting Dimensions
2
2-4-3 Reactor Dimensions
3G3AX-DL2022
3G3AX-AL2025/-AL2055/-AL4025/-AL4055
Model
Dimensions [mm]
A C Y K
3G3AX-AL2025 130 82 67 4
3G3AX-AL2055 140 98 75 4
3G3AX-AL4025 130 82 67 4
3G3AX-AL4055 130 98 75 5
116
105
2-M4
4-6 × 9
86
71
80
100
Ground terminal (M4)
150
92
C
4060
A
Ro R So S To T
Y±1
50±1
Ro R So S To T
9.5
Terminal screw 6-
Ø
K
4-
Ø
6
Ground terminal (M5)
Terminal block
Connection Diagram
(Cutout)
