G5 Series AC Servo Drives With Built-in EtherCAT Communications, Linear Motor Type
*1 The heat value is given for rated operation.
*1 The heat value is given for rated operation.
400-VAC Input Models
Item R88D-KN06F-ECT-L R88D-KN10F-ECT-L R88D-KN15F-ECT-L R88D-KN20F-ECT-L
Input power
supply
Main
circuit
Power supply
capacity
1.2 KVA 1.8 KVA 2.3 KVA 3.8 KVA
Power supply
voltage
3-phase 380 to 480 VAC (323 to 528 V) 50/60 Hz
Rated current 2.1 A 2.8 A 3.9 A 5.9 A
Heat value
*1
32.2 W 48 W 49 W 65 W
Control
circuit
Power supply
voltage
24 VDC (20.4 to 27.6 V)
Heat value
*1
7 W 7 W 7 W 10 W
Weight Approx. 1.9 kg Approx. 1.9 kg Approx. 1.9 kg Approx. 2.7 kg
Maximum
motor
capacity
Rated effective current
of motor
1.5 Arms 2.9 Arms 4.7 Arms 6.7 Arms
Maximum current of
motor
4.5Arms 8.7Arms 14.1Arms 19.7Arms
Item R88D-KN30F-ECT-L R88D-KN50F-ECT-L R88D-KN75F-ECT-L R88D-KN150F-ECT-L
Input power
supply
Main
circuit
Power supply
capacity
4.5 KVA 6.0 KVA 11.0 KVA 22.0 KVA
Power supply
voltage
3-phase 380 to 480 VAC (323 to 528 V) 50/60 Hz
Rated current 7.6 A 12.1 A 16.0 A 29.0 A
Heat value
*1
108 W 200 W 300 W 590 W
Control
circuit
Power supply
voltage
24 VDC (20.4 to 27.6 V)
Heat value
*1
13 W 13 W 15 W 22 W
Weight Approx. 4.7 kg Approx. 4.7 kg Approx. 13.5 kg Approx. 21.0 kg
Maximum
motor
capacity
Rated effective current
of motor
9.4Arms 16.5Arms 22.0Arms 33.1Arms
Maximum current of
motor
28.2 Arms 42.4 Arms 58.7 Arms 83.7 Arms
