2-1 Standard Models
2
Standard Models and Dimensions
 Power Supply Cables
 Personal Computer Monitor Cable
 Connectors
Specifications Model
Power Supply Input Cable for Single-Phase Power (connectors
attached)
2 m R7A-CLB002S2
Power Supply Input Cable for Three-Phase Power (connectors
attached)
2 m R7A-CLB002S3
External Regeneration Resistor Connection Cable 2 m R7A-CLB002RG
Specifications Model
Personal Computer Monitor Cable 2 m R88A-CCG002P2
Specifications Model
Main Circuit Connector (CNA) R7A-CNB01P
Servomotor Connector (CNB) R7A-CNB01A
Control I/O Connector (CN1) R88A-CNW01C
Encoder Input Connector (CN2) R88A-CNW01R
Servomotor Connector for Encoder Cable R88A-CNG02R
Servomotor Connector for Servomotor Power Cable R88A-CNG01A
Brake Cable Connector R88A-CNG01B
