2-1 Standard Models
2
Standard Models and Dimensions
 Servo Relay Units (for CN1)
 Servo Relay Unit Cables for Servo Drives
Specifications Model
Servo Relay Units
For CJ1W-NC133/-NC113
For CS1W-NC133/-NC113
For C200HW-NC113
XW2B-20J6-1B
For CJ1W-NC233/-NC433/-NC213/-NC413
For CS1W-NC233/-NC433/-NC213/-NC413
For C200HW-NC213/-NC413
XW2B-40J6-2B
For CJ1M-CPU21
For CJ1M-CPU22
For CJ1M-CPU23
XW2B-20J6-8A
XW2B-40J6-9A
(for 2 axes)
For FQM1-MMP22 XW2B-80J7-12A
For CQM1H-PLB21
For CQM1-CPU43-V1
XW2B-20J6-3B
Specifications Model
Servo Drive
Cables
For Position Control Unit/CQM1
(XW2B-@J6-@B)
1 m XW2Z-100J-B29
2 m XW2Z-200J-B29
For CJ1M
(XW2B-20J6-8A/XW2B-40J6-9A)
1 m XW2Z-100J-B32
2 m XW2Z-200J-B32
For FQM1-MMP22
(XW2B-80J7-12A)
1 m XW2Z-100J-B30
2 m XW2Z-200J-B30
