4-148
4-4 Communication Function
4
Functions
* Each monitor value
Monitor item Unit Magnification Data size Description
Output frequency Hz × 100 8 bytes Decimal ASCII code
→
MSB
LSB
←
Output current A × 10 8 bytes Decimal ASCII code
Rotation direction  8 bytes
0: Stop, 1: Forward,
2: Reverse
PID feedback monitor % × 100 8 bytes Decimal ASCII code
Multi-function input
monitor
 8 bytes See
*1
.
Multi-function output
monitor
 8 bytes See
*2
.
Frequency conversion
monitor
 × 100 8 bytes Decimal ASCII code
Output torque % × 1 8 bytes Decimal ASCII code
Output voltage monitor V × 10 8 bytes Decimal ASCII code
Power monitor kW × 10 8 bytes Decimal ASCII code
8 bytes
"00000000" is stored.
(Preliminary data storage
area)
RUN time monitor h × 1 8 bytes Decimal ASCII code
ON time monitor h × 1 8 bytes Decimal ASCII code
*1. Multi-function input terminal monitor *2. Multi-function output terminal monitor
Item Data Item Data
S1 terminal 00000001 P1 terminal 00000001
S2 terminal 00000002 P2 terminal 00000002
S3 terminal 00000004 P3 terminal 00000004
S4 terminal 00000008 P4 terminal 00000008
S5 terminal 00000010 P5 terminal 00000010
S6 terminal 00000020 Relay terminal 00000020
S7 terminal 00000040
S8 terminal 00000080
FW terminal 00000100
