7-3 Options
7
Specifications
Specifications
Operating Environment
Inverter
input
power
supply
Model
Figure
No.
Applicable
Inverter
capacity
(kw)
Dimensions (mm) Bmax: coil dimensions
Weight
(kg)
Standard
applicable wire
W D H A B X Y C K
3/1-phase
200 V AC
3G3AX-DL2002
Fig. 1
0.2 669098 85 56 72 5.2 × 8 M4 0.8
1.25 mm
2
min.
3G3AX-DL2004 0.4 66 90 98  95 56 72 5.2 × 8 M4 1.0 1.25 mm
2
min.
3G3AX-DL2007 0.75 66 90 98  105 56 72 5.2 × 8 M4 1.3 2 mm
2
min.
3G3AX-DL2015 1.5 66 90 98  115 56 72 5.2 × 8 M4 1.6 2 mm
2
min.
3G3AX-DL2022 2.2 86 100 116  105 71 80 6 × 9 M4 2.1 2 mm
2
min.
3G3AX-DL2037 3.7 86 100 118  120 71 80 6 × 9 M4 2.6 3.5 mm
2
min.
3G3AX-DL2055
Fig. 2
5..5 111 100 210  110 95 80 7 × 11 M5 3.6 8 mm
2
min.
3G3AX-DL2075 7.5 111 100 212  120 95 80 7 × 11 M6 3.9 14 mm
2
min.
3G3AX-DL2110 11 146 120 252  110 124 96 7 × 11 M6 6.5 22 mm
2
min.
3G3AX-DL2150 15 146 120 256  120 124 96 7 × 11 M8 7.0 38 mm
2
min.
3G3AX-DL2220
Fig. 3
18.5, 22 120 175 356 140 145 98 151 7 × 11 M8 9.0 60 mm
2
min.
3G3AX-DL2300 30 120 175 386 155 150 98 151 7 × 11 M8 13.0 38 mm
2
× 2 min.
3G3AX-DL2370 37 120 175 390 155 150 98 151 7 × 11 M10 13.5 38 mm
2
× 2 min.
3G3AX-DL2450 45 160 190 420 180 150 120 168 7 × 11 M10 19.0 60 mm
2
× 2 min.
3G3AX-DL2550 55 160 190 424 180 180 120 168 7 × 11 M12 24.0 80 mm
2
× 2 min.
3-phase
400 V AC
3G3AX-DL4004
Fig. 1
0.4 669098 85 56 72 5.2 × 8 M4 0.8
1.25 mm
2
min.
3G3AX-DL4007 0.75 66 90 98  95 56 72 5.2 × 8 M4 1.1 1.25 mm
2
min.
3G3AX-DL4015 1.5 66 90 98  115 56 72 5.2 × 8 M4 1.6 2 mm
2
min.
3G3AX-DL4022 2.2 86 100 116  105 71 80 6 × 9 M4 2.1 2 mm
2
min.
3G3AX-DL4037 3.7 86 100 116  120 71 80 6 × 9 M4 2.6 2 mm
2
min.
3G3AX-DL4055 5.5 111 100 138  110 95 80 7 × 11 M4 3.6 3.5 mm
2
min.
3G3AX-DL4075 7.5 111 100 138  115 95 80 7 × 11 M4 3.9 3.5 mm
2
min.
3G3AX-DL4110
Fig. 2
11 146 120 250  105 124 96 7 × 11 M5 5.2 5.5 mm
2
min.
3G3AX-DL4150 15 146 120 252  120 124 96 7 × 11 M6 7.0 14 mm
2
min.
3G3AX-DL4220
Fig.3
18.5, 22 120 175 352 140 145 98 151 7 × 11 M6 9.5 22 mm
2
min.
3G3AX-DL4300 30 120 175 356 140 145 98 151 7 × 11 M8 9.5 30 mm
2
min.
3G3AX-DL4370 37 120 175 386 155 150 98 151 7 × 11 M8 13.5 38 mm
2
min.
3G3AX-DL4450 45 160 190 416 180 145 120 168 7 × 11 M8 16.5 60 mm
2
min.
3G3AX-DL4550 55 160 190 416 190 170 120 168 7 × 11 M8 23.0 38 mm
2
× 2 min.
Ambient temperature -10°C to 50°C
Humidity 20% to 90% RH (with no condensation)
Vibration
15 kW max. 5.9 m/s
2
max. (0.6G) 10 to 55 Hz
22 kW min. 2.0 m/s
2
max. (0.2G) 10 to 55 Hz
Location At a maximum altitude of 1,000 m; indoors (without corrosive gases or dust)
