Omron Sysdrive RX Series - Parameter List

3-19
3-7 Parameter List
3
Operation
3-7 Parameter List
Monitor Mode (d)
•The default setting displays "d001" at power-on. To select the optional display, change the setting
in "b038".
Parameter
No.
Function name Monitor or data range
Default
setting
Changes during
operation
Unit Page
Normal
b031 = 10
d001
Output frequency
monitor
0.0 to 400.0 
Yes 
Hz 4-1
d002
Output current
monitor
0.0 to 999.9
1000 to 9999


A4-1
d003
Rotation direction
monitor
F: Forward
o: Stop
r: Reverse


 4-1
d004
PID feedback value
monitor
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
1000 to 9999 (10000 to 99990)
⎡100 to ⎡999 (100000 to 999000)
(Enabled when the PID function is selected)


 4-1
d005
Multi-function input
monitor


 4-2
d006
Multi-function
output monitor


 4-2
d007
Output frequency
monitor
(after conversion)
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
1000 to 3996 (10000 to 39960)
(Output frequency × Conversion factor of b086)

Yes 
 4-2
d008
Real frequency
monitor
-400. to -100.
-99.9 to 0.00 to 99.99
100.0 to 400.0


Hz 4-3
d009
Torque reference
monitor
-200. to +200. 

%4-3
d010
Torque bias
monitor
-200. to +200. 

%4-3
d012
Output torque
monitor
-200. to +200. 

%4-3
d013
Output voltage
monitor
0. to 600. 

V4
-4
FW
S8 S7 S6 S5 S4 S3 S2 S1
(Example) Terminals FW, S7, S2, S1 : ON
Terminals S8, S6, S5, S4, S3: OFF
MA P5 P4 P3 P2 P1
(Example) Terminals P2, P1 : ON
Terminals MA, P5, P4, P3: OFF
