7-2 Dimensional Drawing
7
Specifications
7-2 Dimensional Drawing
3G3RX-A2004/A2007/A2015/A2022/A2037
A4004/A4007/A4015/A4022/A4037
150
2-φ6
130
130
143
80
6
79140
62
241
255
