118
Yes
No
Check the voltage at
the IR 00002 and IR
00003 terminals.
Check operation by using a
dummy input signal to turn the
input ON and OFF.
No
Replace the Input
Unit.
Are the terminal
screws loose?
Operation
O.K.?
Wire correctly.
Is input wiring
correct?
Tighten the terminal
screws
Replace terminal
connector.
Is terminal
block making proper
contact?
Check input devices
LS1 and LS2.
Return to “start.”
Are the IR 00002
and IR 00003 input indi-
cators operating
normally?
Operation
O.K.?
Replace the Output
Unit.
Operation
O.K.?
Yes
Yes
Yes
Yes
NoNo
No
No
No
No
No
Yes
No
Check the voltage at
the IR 00002 and IR
00003 terminals.
A
From
previous
page
Troubleshooting Flowcharts
Section 4-6
