Appendix AStandard Models
122
Input Units
Name Model number Specifications
DC Input Units
CQM1-ID111 16 points, 12 VDC
CQM1-ID112 32 points, 12 VDC
DC Input Units
CQM1-ID211 8 points, 12 to 24 VDC (independent commons)
CQM1-ID212 16 points, 24 VDC
CQM1-ID213 32 points, 24 VDC
CQM1-ID214 32 points, 24 VDC
AC Input Units
CQM1-IA121 8 points, 100 to 120 VAC
CQM1-IA221 8 points, 200 to 240 VAC
Output Units
Name Model number Specifications
Contact Output Units
CQM1-OC221 8 points, 250 VAC/24 VDC, 2 A (independent commons, 16 A per Unit)
CQM1-OC222 16 points, 250 VAC/24 VDC, 2 A (8 A per Unit)
CQM1-OC224 8 points, 250 VAC/24 VDC, 2 A (independent commons, 16 A per Unit)
Transistor Output Units
CQM1-OD211 8 points, 24 VDC, 2 A (5 A per Unit)
CQM1-OD212 16 points, 4.5 to 26.4 V, 0.3 A
CQM1-OD213 32 points, 4.5 to 26.4 V, 0.1 A
CQM1-OD214 16 points, 4.5 to 26.4 V, 0.3 A, PNP output
CQM1-OD215 8 points, 24 VDC, 1 A (4 A/Unit), PNP output, with short-circuit protection
Triac Output Unit
CQM1-OA221 8 points, 100 to 240 VAC, 0.4 A
CQM1-OA222 6 points, 100 to 240 VAC, 0.4 A
Dedicated I/O Units
Name Model number Specifications
B7A Interface Units
CQM1-B7A02 16 output points
CQM1-B7A03 32 output points
CQM1-B7A12 16 input points
CQM1-B7A13 32 input points
CQM1-B7A21 16 input points and 16 output points
I/O Link Unit CQM1-LK501 32 input points, 32 output points (SYSMAC BUS Wired Slave Unit)
Analog Input Unit CQM1-AD041 4 analog input points
Analog Output Unit
CQM1-DA021
2 analog output points
Power Supply Units
CQM1-IPS01 Power supply for Analog Input or Output Unit (1-unit type)
CQM1-IPS02 Power supply for Analog Input or Output Unit (2-unit type)
Sensor Unit CQM1-SEN01 Sensor input points: 4 max.
Used with Sensor Module(s). Up to four Sensor Modules can be mounted
to a single Sensor Unit.
Linear Sensor Interface
CQM1-LSE01 Standard model
Units
CQM1-LSE02 With monitor output
Fiber Photoelectric
Module
E3X-MA11 For E32 series Fiber Units. An automatic teaching function is incorporated.
Photoelectric Module
with Separate Amplifier
E3C-MA11 For E3C-series Photoelectric Sensors. An automatic teaching function is
incorporated.
Proximity Module with
Separate Amplifier
E2C-MA11 For E2C-series Proximity Sensors. An automatic teaching function is
incorporated.
Dummy Module E39-M11 E39-M11 Dummy Modules are mounted as spacers to the open slots of
the CQM1 when no Sensor Module is mounted to the CQM1.
Remote Console CQM1-TU001 The Remote Console is connected to a Sensor Unit for the adjustment of
the sensitivities of the modules incorporated by the Sensor Unit, reading
and changing of the set value, and teaching.
Cable length: 3 m
