Revision History
A manual revision code appears as a suffix to the catalog number on the front cover of the manual.
Cat. No. W226-E1-5
Revision code
The following table outlines the changes made to the manual during each revision. Page numbers refer to the
previous version.
Revision code Date Revised content
1 August 1993 Original production
1A October 1993
The new LSS version which was “to be released soon” has
been released.
Page 3: Minor alteration to the Main Features.
Page 9: MONITOR Mode and RUN Mode corrected.
Page 10: Table comments corrected.
Page 18: Diagrams and note corrected for Power Supply Unit Wiring.
Page 19: Surge current changed to inrush current. Corrections made
to the diagram text and to I/O Line Noise text.
Page 20: Minor correction to middle diagram.
Page 21: Circuit diagrams corrected.
Page 22: Peripheral Device Connection rewritten.
Page 23: Minor correction to diagram.
Page 25: Output capacity and vibration resistance specifications
clarified.
Page 26: MACRO instruction words, Timers/Counters, and Data
memory specifications clarified.
Page 28: Internal current consumption clarified, CQM1-ID212 Termi-
nal Connections corrected, and note added.
Page 29: Internal current consumption clarified.
Page 30: Internal current consumption and Service Power Supply
clarified, and Circuit Configuration corrected.
Page 31: Internal current consumption clarified, Service Power Sup-
ply and Circuit Configuration corrected.
Page 36: Cable length for the CQM1-PRO01-E corrected. Keypad
for the C200H-PRO27-E changed.
Page 38: Minor change to the diagram.
Page 39: Header changed to Reading/Clearing Error Messages.
Step 2 display of the key sequence for Reading/Clearing Error Mes-
sages corrected.
Page 40: Step 1 of the key sequence for Buzzer Operation cor-
rected.
Pages 41, 42: Displays for Reading and Changing Expansion
Instructions and Reading and Changing the Clock have been cor-
rected.
Page 43: Steps 3 and 5 displays of the key sequence for Instruction
Search corrected.
Page 45: Step 5 display of the key sequence for Entering or Editing
Programs corrected.
Pages 48, 49: Steps 3 and 5 displays for Multiple Address Monitor-
ing corrected.
Page 49: Step 2 display for Binary Monitor corrected.
Page 51: Steps 3 and 4b displays for Changing Timer, Counter SV
corrected.
Page 52: Steps 3 and 5 displays for Multiple Address Monitoring
corrected.
Page 53: Bits in SR words corrected.
Page 54: Step 2 text addition for Force Set, Reset.
Page 58: Text addition to Operating Errors.
Page 59: REPL ROM Programming Console operation error rewrit-
ten.
Pages 61, 62: Note added to the bottom of both pages.
Pages 63 to 65: Minor corrections to the flowcharts.
2 December 1993
The manual was extensively rewritten to incorporate information on the new CPUs, I/O Units, and Dedicated I/O Units.
2A October 1994
Page 34: Computational speed specifications corrected for the Pulse
Input Port (CQM1-CPU43-E) table.
Page 35: Output frequency row added to the table.
Page 47: Terminal connections corrected.
2B March 1995
Pages 2, 3, 7, 29, 87: SYSMAC Support Software (SSS) added.
Page 15: The “1 kHz” corrected to “4 kHz” in the first sentence of
2-1-10 ABS Interface Function.
Page 13: A section on Programmable Controller Power Instructions
added.
Page 17: New Dedicated I/O Units added.
Page 33: Data for Types of Instructions, Input Bits, Output Bits, and
Work Bits corrected.
Page 40: Computational speed changed from “1 kHz” corrected to “4
kHz” in the table.
Pages 43, 45, 46, 47, 48, 49, 50, 52, 53, 55: Corrections made to the
Terminal Connections.
Page 59: 3-2 SSS Capabilities added.
Pages 65, 74, 75: SET Key corrected to SHIFT Key.
Page 66: Text after the table deleted and SET Key corrected to
SHIFT Key in 3-4-6 Reading and Changing the Clock.
Page 73: “6 bits” corrected to “16 bits” in the first sentence of 3-4-13
Bit, Digit, Word Monitor. SET Key corrected to SHIFT Key for the Bit
Monitor sequence.
Page 84: “DM data” corrected to “word data” in 3-4-27 Hex-ASCII
Display Change. 3-5-29 Inputting Signed Binary Data Using Decimal
Values and 3-5-30 Using Signed Binary Instructions added.
Page 101: Output Units specifications corrected. New Dedicated I/O
Units and SSS added.
2C July 1995
The following changes and additions were made.
Page 7: Default communications settings modified and notes added
to table.
Page 12: Reference added to the top paragraph.
Pages 17 and 110: DC Input Unit models and Linear Sensor Inter-
face Units added.
Page 18: DC Input Unit models added.
Pages 45 and 46 : CQM1-ID111 and CQM1-ID112 added (new
pages).
Page 102: Note corrected.
Page 115: Appendix B Battery Service Life added.
2D July 1996
Pages 16, 17, 20, 23, 32, 111: CQM1-PA216 added.
Pages 17, 18, 59, 112: CQM1-OA222 added.
Pages 17, 113: DeviceBus/S Units added.
Pages 23, 24: Terminal Block rewritten and Wiring Precautions
for Ground Wires added.
Page 51: Circuit configuration corrected for CQM1-OD211.
Page 56: Circuit configuration corrected for CQM1-OD215.
Pages 77, 83: Set Key corrected to Shift Key for the top display.
Page 80: The program addresses corrected from 00202 to
00203.
Page 105: ERR/ALM corrected to RUN at the bottom of the flow-
chart.
3 April 1997
Pages 17, 18, 19, 52, 116: CQM1-OC224 added. Page 28: 2-5-5 Compliance with EC Directives added.
4 June 1997
CQM1-CPU4j-E CPU Unit model numbers changed to CQM1-CPU4j-EV1 throughout the manual.
Page 6: Maximum I/O points for CQM1-CPU4j-EV1 CPU Units changed from 192 to 256.
5 February 1999 PRECAUTIONS section added before Section 1. Appendix C SYSMAC-CPT
Precautions added.
Page 20: Changes made to 2-3-1 Maximum No. of I/O Units and I/O Points.
Page 30: Precautions in Connecting 2-wire DC Sensors added.
Page 38: Vibration resistance and shock resistance specifications corrected in
2-6-1 Power Supply Units.
Pages 18, 19, 54, 120: Information for the new C200H-ID214 added.
