Omron SYSMAC CQM1-ID212 - DIN Track and Accessories; Peripheral Devices

Appendix AStandard Models
123
Name SpecificationsModel number
G730 Interface Units
CQM1-G7M21 Master: 32 inputs and 32 outputs
CQM1-G7N01 Expansion Master: 32 outputs
CQM1-G7N11 Expansion Master: 32 inputs
Temperature Control
CQM1-TC001 Thermocouple input, transistor (NPN) output, 2 loops
Units
CQM1-TC002 Thermocouple input, transistor (PNP) output, 2 loops
CQM1-TC101 Platinum resistance thermometer, transistor (NPN) output, 2 loops
CQM1-TC102 Platinum resistance thermometer, transistor (PNP) output, 2 loops
CompoBus/S
Master Unit
CQM1-SRM21 128 points (64 inputs and 64 outputs); 64 points (32 inputs and 32
outputs); 32 points (16 inputs and 16 outputs)
Switchable
CompoBus/D (DeviceNet)
I/O Link Unit
CQM1-DRT21 16 inputs and 16 outputs (total: 32 points)
DIN Track and Accessories
Name Model number Specifications
DIN Track
PFP-50N Track length: 50 cm; track height: 7.3 cm
PFP-100N Track length: 100 cm; track height: 7.3 cm
DIN Track Brackets PFP-M Two required for each PC mounted to DIN Track.
Peripheral Devices
Name Model number Specifications
Programming Console
CQM1-PRO01-E 2-m Connecting Cable attached
C200H-PRO27-E Hand-held, w/backlight; requires the C200H-CN222 or
C200H-CN422, see below
Ladder Support Software
C500-SF312-EV3 3.5”, 2HD for IBM PC/AT compatible
(see note)
C500-SF711-EV3 5.25”, 2D for IBM PC/AT compatible
SYSMAC Support Software C500-ZL3AT1-E 3.5”, 2HD for IBM PC/AT compatible
Connecting Cable
CQM1-CIF02 Connects IBM PC/AT or compatible computers to Peripheral Port
C200H-CN222 Connects C200H Programming Console to Peripheral Port (2 m)
C200H-CN422 Connects C200H Programming Console to Peripheral Port (4 m)
Note Use Version-3 LSS or a later version for CQM1 operation.
Memory Cassettes (Optional)
Model number Clock function Memory
CQM1-ME04K No
4K-word EEPROM
CQM1-ME04R Yes
CQM1-ME08K No
8K-word EEPROM
CQM1-ME08R Yes
CQM1-MP08K No
EPROM IC socket only. EPROM chip not included. Refer to the following
CQM1-MP08R Yes
table for details on available EPROM ICs.
EPROM ICs
Model number EPROM version Capacity Access speed
ROM-ID-B 27128 16K bytes 150 ns
ROM-JD-B 27256 32K bytes 150 ns
ROM-KD-B 27512 64K bytes 150 ns
