Changing the Timer/Counter PV Refresh Mode Section 6-4
Instructions and Operands
Timer and Counter Instructions
TIMER (100 ms)
HIGH-SPEED TIMER (10 ms)
ONE-MS TIMER (1 ms)
ACCUMULATIVE TIMER (100 ms)
LONG TIMER (100 ms)
MULTI-OUTPUT TIMER (100 ms)
Instruction name BCD mode Binary mode
Mnemonic TIM TIMX(550)
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TIMH(015) TIMHX(551)
S (timer set value) #0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.01 s) 0 to 99.99 s 0 to 655.35 s
Instruction name BCD mode Binary mode
Mnemonic TMHH(540) TMHHX(552)
S (timer set value) #0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.001 s) 0 to 9.999 s 0 to 65.535 s
Instruction name BCD mode Binary mode
Mnemonic TTIM(087) TTIMX(555)
S (timer set value) #0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TIML(542) TIMLX(553)
S, S+1 (timer set values) #00000000 to #99999999
(BCDÅj
&0 to &4294967295 (deci-
mal)
or #0000 to #FFFFFFFF
(hexadecimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic MTIM(543) MTIMX(554)
S to S-7 (each timer set
value)
#0000 to #9999 (BCDÅj &0 to &65535
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
