283
Changing the Timer/Counter PV Refresh Mode Section 6-4
COUNTER
REVERSIBLE COUNTER
RESET TIMER/COUNTER
Block Program Instructions
TIMER WAIT (100 ms)
HIGH-SPEED TIMER WAIT (10 ms)
COUNTER WAIT
Instruction name BCD mode Binary mode
Mnemonic CNT CNTX(546)
S (counter set value) #0000 to #9999 (BCDÅj &0 to& 65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
Instruction name BCD mode Binary mode
Mnemonic CNTR(012) CNTRX(548)
S (counter set value) #0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
Instruction name BCD mode Binary mode
Mnemonic CNR(545) CNRX(547)
Instruction name BCD mode Binary mode
Mnemonic TIMW(813) TIMWX(816)
S (timer set value) #0000 or# 9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TMHW(815) TMHWX(817)
S (timer set value)
Unit: 0.01 s
#0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.01 s) 0 to 999.9 s 0 to 655.35 s
Instruction name BCD mode Binary mode
Mnemonic CNTW(814) CNTWX(818)
S (counter set value) #0000 to #9999 (BCDÅj &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
