Omron SYSMAC CS/CJ Series User Manual

337
PLC Comparison Charts Appendix A
Timer and
Counter
Instructions
TIMER TIM
(BCD)
Yes Yes Yes Yes Yes
TIMX
(binary)
Yes(*4) Yes(*4) No No No
HIGH-SPEED
TIMER
TIMH
(BCD)
Yes Yes Yes Yes Yes
TIMHX
(binary)
Yes(*4) Yes(*4) No No No
ONE-MS TIMER TMHH
(BCD)
Yes Yes No No No
TMHHX
(binary)
Yes(*4) Yes(*4) No No No
ACCUMULATIVE
TIMER
TTIM
(BCD)
Yes Yes Yes Yes Yes
TTIMX
(binary)
Yes(*4) Yes(*4) No No No
LONG TIMER TIML
(BCD)
Yes Yes No Yes No
TIMLX
(binary)
Yes(*4) Yes(*4) No No No
MULTI-OUTPUT
TIMER
MTIM
(BCD)
Yes Yes No Yes No
MTIMX
(binary)
Yes(*4) Yes(*4) No No No
COUNTER CNT
(BCD)
Yes Yes Yes Yes Yes
CNTX
(binary)
Yes(*4) Yes(*4) No No No
REVERSIBLE
COUNTER
CNTR
(BCD)
Yes Yes Yes Yes Yes
CNTRX
(binary)
Yes(*4) Yes(*4) No No No
RESET TIMER/
COUNTER
CNR
(BCD)
Yes (Only resets
timer or
counter.)
Yes (Only resets
timer or
counter.)
No Yes (Also clears
specified range
in CIO area to
zero.)
No
CNRX
(binary)
Yes(*4) Yes(*4) No No No
Compari-
son Instruc-
tions
Symbol compari-
son
=, <,
etc.
Yes (All are sup-
ported for LD,
OR, and AND)
Yes (All are sup-
ported for LD,
OR, and AND)
Yes (*2) (Sup-
ported for AND
only)
Yes (*1) (Sup-
ported for AND
only)
No
COMPARE/
DOUBLE
COMPARE
CMP/
CMPL
Yes Yes Yes Yes (*3) Yes
SIGNED BINARY
COMPARE/
DOUBLE SIGNED
BINARY COM-
PARE
CPS/
CPSL
Yes Yes Yes Yes (*1) Yes
BLOCK COM-
PARE
BCMP Yes Yes Yes Yes Yes
EXTENDED
BLOCK COMPARE
BCMP2 Yes (CJ1M CPU
Units only)
No No No No
TABLE COMPARE TCMP Yes Yes Yes Yes Yes
MULTIPLE
COMPARE
MCMP Yes Yes Yes Yes Yes
EQUALSEQUNoNoNoYesNo
AREA RANGE
COMPARE
ZCP/
ZCPL
CJ1: No
(achieved using
comparison
instructions)
CJ1-H: Yes
CJ1M: Yes
CS1: No
(achieved using
comparison
instructions)
CS1-H: Yes
Yes No No (achieved
using compari-
son instructions)
Item Mne-
monic
CJ Series CS Series C200HX/HG/HE CVM1/CV
Series
CQM1H
