Pin locations for
terminal block
○: Pin inserted
Terminal block Unit
1 2 3 4 5 6
○No.1 ○ ○
○No.2 ○ ○
○No.3 ○ ○
○No.4 ○ ○
○No.5 ○ ○
○No.6 ○ ○
○No.7 ○ ○
○No.8 ○ ○
○No.9 ○ ○
○No.10 ○ ○
No.11 ○ ○ ○
No.12 ○ ○ ○
No.13 ○ ○ ○
No.14 ○ ○ ○
No.15 ○ ○ ○
No.16 ○ ○ ○
No.17 ○ ○ ○
No.18 ○ ○ ○
No.19 ○ ○ ○
No.20 ○ ○ ○
1 2 3 4 5 6
○ ○ ○
○ ○ ○
○○ ○
○○ ○
○ ○ ○
○○ ○
○○ ○
○○ ○
○○ ○
○○○
○ ○ ○
○○ ○
○○ ○
○○ ○
○○ ○
○○○
○○ ○
○○ ○
○○○
○○○
1
2
3
4
5
6
1
2
3
4
5
6
Holes used by
OMRON
Holes for incorrect
attachment prevention
(pin locations)
Pin locations for Unit
Pattern
Holes used by
OMRON
Holes for incorrect
attachment prevention
(pin locations)
Two sets of NX-AUX02 Pins are required to make the maximum of 20 pin patterns. (One set for 10
Units.)
4 Installation and Wiring
4-57
NX-series System Units User's Manual (W523)
4-9 Wiring the Terminals
4
4-9-2 Preventing Incorrect Attachment of Terminal Blocks
