Version Information with Communica-
tion Control Units
This section provides version-related information when connecting Units to a Communication Control
Unit.
This section describes the relationship between the unit versions of each Unit and the Communication
Control Unit, and Sysmac Studio version, and the specification changes for each unit version of each
Unit.
A-7-1
Relationship between Unit Versions of Units
The relationship between the unit versions of each Unit and the Communication Control Unit, and Sys-
mac Studio version are shown below.
Interpreting the Version Combination Tables
The items that are used in the version combination tables are given below.
NX Unit Corresponding unit versions/versions
Model Unit version
Communication Control
Unit
Sysmac Studio
Model numbers of NX
Units.
Unit versions of NX Units. Unit versions of the Com-
munication Control Unit
that are compatible with
the NX Units.
Sysmac Studio versions
that are compatible with
the NX Units and Commu-
nication Control Unit.
Version Combination Tables
• With the combinations of the unit versions/versions shown below, you can use the functions that are
supported by the unit version of the Unit model. Use the unit versions/versions (or the later/higher
unit versions/versions) that correspond to the NX Unit models and the unit versions. You cannot use
the specifications that were added or changed for the relevant NX Unit models and the unit versions
unless you use the corresponding unit versions/versions.
•
Depending on the type and model of the Unit to which the NX Unit is connected, some Units do not
have the corresponding versions given in the table. If a Unit does not have the specified version,
support is provided by the oldest available version after the specified version. Refer to the user’s
manuals for the specific Units for the relation between models and versions.
• You cannot connect the relevant NX Unit to the Communication Control Unit if "---" is shown in the
corresponding unit versions/versions column.
• If you use the corresponding unit versions/versions given in the following table or later/higher ver-
sions, refer to the version information in the user’s manual for the Communication Control Unit.
Appendices
A-34
NX-series System Units User's Manual (W523)
