Omron Sysmac NX-PD1000 User Manual

• You cannot connect the relevant NX Unit to the target Communications Coupler Unit if "---" is shown
in the corresponding unit versions/versions column.
• If you use the corresponding unit versions/versions given in the following table or later/higher ver-
sions, refer to the version information in the user
’s manual for the Communications Coupler Unit,
CPU Unit, and Industrial PC.
NX Unit Corresponding unit versions/versions
Model
Unit
version
Application with an NJ/NX/NY-series Con-
troller
*1
Application with a CS/CJ/CP-series PLC
*2
EtherNet/IP
Coupler Unit
CPU Unit or
Industrial PC
Sysmac
Studio
EtherNet/IP
Coupler Unit
Sysmac
Studio
NX-IO Con-
figurator
*3
NX-PD1000
Ver.1.0 Ver.1.2 Ver.1.14 Ver.1.19 Ver.1.0 Ver.1.10 Ver.1.00
NX-PF0630
NX-PF0730
NX-PC0020
NX-PC0010
NX-PC0030
NX-TBX01
*1. Refer to version information in the user's manual of the EtherNet/IP Coupler Unit for the unit versions of Ether-
Net/IP Units corresponding to EtherNet/IP Coupler Units.
*2. Refer to version information in the user's manual of the EtherNet/IP Coupler Unit for the unit versions of CPU
Units and EtherNet/IP Units corresponding to EtherNet/IP Coupler Units.
*3. For connection to an EtherNet/IP Coupler Unit with unit version 1.0, connection is supported only for a con-
nection to the peripheral USB port on the EtherNet/IP Coupler Unit. You cannot connect by any other path. If
you need to connect by another path, use an EtherNet/IP Coupler Unit with unit version 1.2 or later.
Appendices
A-33
NX-series System Units User's Manual (W523)
A-6 Version Information with Communications Coupler Units
A
A-6-2 Connection to an EtherNet/IP Coupler Unit
