Commercially Available Markers
Commercially available markers are made of plastic and can be printed on with a special printer.
To use commercially available markers, purchase the following products.
Product name
Model number
Manufactured by Phoenix Contact Manufactured by Weidmuller
Markers UC1-TMF8 DEK 5/8
Special marker printer UM EN BLUEMARK X1 PrintJet PRO
The markers made by OMRON cannot be printed on with commercially available special printers.
4-1-3
Removing NX Units
This section describes how to remove NX Units.
Precautions for Safe Use
Always turn OFF the Unit power supply and I/O power supply before you remove the NX Unit.
1 Use a flat-blade screwdriver or similar tool to pull up the DIN Track mounting hook on the NX
Unit to remove.
Flat-blade screwdriver
DIN Track mounting hook
2 Place your fingers on the protrusions on more than one NX Unit, including the NX Unit to re-
move, and pull the NX Units straight forward.
4 Installation and Wiring
4-6
NX-series System Units User's Manual (W523)
