Omron Sysmac NX-PD1000 User Manual

A-2
Dimensions
A-2-1
Additional NX Unit Power Supply Unit, Additional I/O Power Sup-
ply Unit, I/O Power Supply Connection Unit, and Shield Connec-
tion Unit
12 mm Width
80
71
104.5
100
14.1
65.2
12.0
1.5 1.5
0.55
*1
(Unit: mm)
*1. The dimension is 1.35 mm for Units with lot numbers through December 2014.
Appendices
A-23
NX-series System Units User's Manual (W523)
A-2 Dimensions
A
A-2-1 Additional NX Unit Power Supply Unit, Additional I/O Power Supply Unit, I/O Power Supply Connection Unit, and Shield Connection Unit
