Precautions for Correct Use
You can mount either NX-TB£££1 or NX-TB£££2 Terminal Blocks to the Units that the cur-
rent capacity specification of the terminals is 4 A or less.
However
, even if you mount the NX-TB£££2 Terminal Block, the current specification does
not change because the current capacity specification of the terminals on the Units is 4 A or
less.
Additional Information
Refer to A-4 List of Screwless Clamping Terminal Block Models on page
A-27 for information
on the models of terminal blocks.
3 Part Names and Functions
3-5
NX-series System Units User's Manual (W523)
3-1 Names of Power Supply-related Unit Parts
3
3-1-1 Screwless Clamping Terminal Block Type
