Section 5 Communications Commands
RFID System
Operation Manual
Section 5
Communications
■ 1:N Communications
Data code specification Specifies the type of code in which the write data is being sent.
A: ASCII
H: Hexadecimal
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read/Write Head 1
2: Read/Write Head 2
Write area start address Specifies the first address to which to write data to the Data Carrier as a four-digit hexadecimal
number.
Specifiable range: 0000H to FFFFH
Write data The data to write to Data Carrier memory. Up to 256 bytes can be written with one command.
• ASCII specification: 256 bytes (256 characters)
• Hexadecimal code specification: 256 bytes (512 characters)
Note: When using hexadecimal code, set two characters for each byte.
End code Indicates the results of command execution. An end code of 00 is returned for a normal end.
Refer to End Codes for more information.
p.135
xx
AW
xx
A/H 1/2
xx
211 4
2
*CR
n
xx
2
xx
FCS
3
x
@ x
Write data
Terminator
Controller No.
Command code
Write area start address
Data code
specifica-
tion
R/W Head No.
Command
Response
Command code
AW
00
22
2
*CR
Terminator
End code
xx
2
FCS
3
Controller No.
x
@ x

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
