Omron V600 Series User Manual

RFID System
Operation Manual
Section 6 Troubleshooting Flowcharts
Section 6
Troubleshooting
143
Troubleshooting Flowcharts
If a malfunction has occurred, carefully investigate the surrounding conditions and check whether the trouble persists or is
related to other equipment. Then troubleshoot the malfunction according to the following flowcharts.
Main Check Flowchart
Main Check Flowchart
YES
YES
To Systems Connections Check
To Host Communications Check
To Data Carrier Communications
Check
To Application Conditions and
External Environment Check
OK
NO
NO
YES
NO
YES
NO
System
connections
normal?
Make a decision for the main check
flowchart depending on the nature of
the error.
Application
conditions and
external environment
normal?
Communications
with host device
normal?
Communications
with Data Carrier
normal?
p.144
p.145
p.146
p.147

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
