Section 7 Specifications and Dimensions
RFID System
Operation Manual
Section 7
Appendix
Specifications and Dimensions
General Specifications
Communications specifications
Item
Specification
RS-232C RS-422/RS-485
Connector specifica-
tions
9-pin D-Sub connector, socket lock screws: M2.6 5-pin connector manufactured by Phoenix Contact
MC1.5/5GF-3.5
Communications
method
Half-duplex serial communications 4/2-wire half-duplex serial communications
Baud rate 38400, 19200, 9600, 4800, 2400, or 1200 bps
Data length 7 or 8 bits
Stop bits 1 or 2 bits
Error detection Parity (even, odd, or none)
Cable length 15 m max. Total length: 500 m max.
Item
Specification
V600-CAD01 V600-CAD02
Power supply voltage 24 VDC (15% to 10%)
Power consumption/current consumption Power consumption: 15 W, current consumption: 0.8 A
Ambient operating temperature 10 to 55C (with no icing)
Ambient operating humidity 25% to 85% (with no condensation)
Ambient storage temperature 25 to 65C (with no icing)
Ambient storage humidity 25% to 85% (with no condensation)
Insulation resistance Between power supply terminals and GR/case
Between GR and terminals
Dielectric strength Between power supply terminals and GR/case
Between GR and terminals
Vibration resistance 10 to 150 Hz with 0.2 mm double amplitude and 15-m/s
2
maximum acceleration, 10
sweeps of 8 minutes each in three directions
Shock resistance 150 m/s
2
Dimensions 105 90 65 mm (excluding protrusions)
Degree of protection In-panel (equivalent to IP20)
Materials PC+ABS
Weight Approx. 300 g
Installation method DIN Rail or M4 screws
Read/Write Head Connections 1 channel 2 channels
20 M min. (at 500 VDC)
1,000 VAC 50/60 Hz for 1 minute,
leakage current: 10 mA max.
