Omron V600 Series User Manual

57
RFID System
Operation Manual
Section 3 Test Operation
Section 3
Preparing Communications
Test Operation
Power turned ON.
Test operation of external
I/O terminal functions.
• Check the power supply voltage and power supply terminal connections.
• Check the power supply voltage to the I/O terminals.
• Check the POWER indicators on the ID Controller and Read/Write Head.
• Confirm that operation stops for the reset input.
• Check status for trigger inputs in I/O Display Mode.
• Test communications between the Data Carriers and I/o Controller
without connecting to the host device.
• Text communications between the host device and ID Controller with
the TEST command.
• Test the entire system using actually commands and I/O status.
Perform offline tests in
MAINTENANCE mode.
Perform online tests
with the host device.
Test system operation.
End.

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
