Section 5 End Codes
Section 5
Communications
End Codes
End codes are given by two hexadecimal digits.
Note: Data processing has been normally completed for an error code of 7B. If communications are not
possible because of a low battery, an error response (e.g., with error code 72 will be returned.)
For more details on errors, refer to Error Lists.
p.139
Type End code Name
Normal 00 Normal end code
74 Polling Command received, Polling Command Check (no results)
75 Auto Command canceled before a Data Carrier was detected.
Polling Command canceled before a Data Carrier was detected.
Normal end code for a MANAGEMENT DATA CHECK/CALCULATE command or
MANAGEMENT DATA SUBTRACTION/LIMIT command (not an error)
76 Auto Command canceled after a Data Carrier was detected.
Polling Command canceled after a Data Carrier was detected.
Host communications
errors
10 Parity error
11 Framing error
12 Overrun error
13 FCS error
14 Format error
Execution status error
18 Frame length error
Data Carrier communica-
tions errors
70 Data Carrier communications error
71 Mismatch error
72 Data Carrier missing error
76 Copy error
7A Address error
7C Read/Write Head not connected
7D Write-protected
Data Carrier memory
warnings
7B Battery low warning (Replace the battery or Data Carrier.) (See note.)
76 Error end code for a MANAGEMENT DATA CHECK/CALCULATE command or
MANAGEMENT DATA SUBTRACTION/LIMIT command (verification error or
overwrite limit exceeded)
System errors 92 Antenna section power supply voltage error
93 Internal memory error

Omron V600 Series Specifications

General

Operating Frequency	13.56 MHz
Supported Standards	ISO 15693, ISO 18000-3
Read Range	Up to 70 mm (depending on tag and environment)
Power Supply	24 VDC ±10%
Operating Temperature	-10 to 55°C (with no icing or condensation)
Humidity	35% to 85% (non-condensing)
Communication Interface	RS-232C
