109
RFID System
Operation Manual
Section 5 Communications Commands
Section 5
Communications
Check/end specification Specifies checking processing results or ending (terminating) the command.
C: Check processing
E: End
R/W Head No. Specifies the Read/Write Head with which to communicate.
1: Read/Write Head 1
2: Read/Write Head 2
End code Indicates the results of command execution.
00: Normal end
74: A Data Carrier has not approached when the command to check results was executed.
75: A Data Carrier has not approached when polling auto processing was ended.
76: Communications with the Data Carrier were in process or processing was finished when poll-
ing auto processing was ended.
Refer to End Codes for more information.
p.135
Read data Indicates the read data for the executed command.
Command code
PR
C/E 1/2
2
2
*CR
Terminator
Check/end specification
11
R/W Head No.
Subcommands
Subcommand Responses
x
Command code
PR
x
00
xx
22 n
2
*CR
Terminator
Read dataEnd code
