Omron V640 Series User Manual

43
CIDRW System
User’s Manual
SECTION 4
Command/Response Format
SECTION 4
Reading from/Writing to ID Tags
The response code (00: normal) and MAC address are returned.
* The above response is for a MAC address of 00:1F:16:1A:B9:8E.
Example 4: Checking If Network Settings on DIP Switch on Amplifier Unit Are Enabled or Disabled
The response code (00: normal) and enabled/disabled status of the DIP switch network settings are
returned.
* The above response is for when the DIP switch settings are enabled. The response will show 00 for disabled status.
Example 5: Checking IP Address on DIP Switch on Amplifier Unit
The response code (00: normal) and IP address on the DIP switch (decimal, four octets of 3 digits
each) are returned.
* The above response is for when the IP address on the DIP switch is 192.168.1.20.
* The following response will be returned if the DIP switch network settings are disabled.
Response code MAC address CR
0 0 001F161AB98E0Dh
Command code
Parameter
type
CR
14100Dh
Response
code
DIP switch
enabled/disabled
CR
00 0 10Dh
Command code
Parameter
type
CR
14110Dh
Response
Command
Response
Command
Response
Response code IP address on DIP switch CR
0 0 1921680010200Dh
First octet
Second octet
Third octet
Fourth octet
Response code IP address on DIP switch CR
0 0 0000000000000Dh
First octet
Second octet
Third octet
Fourth octet
