SECTION 4
Command/Response Format
CIDRW System
User’s Manual
SECTION 4
Reading from/Writing to ID Tags
Example 6: Checking the Subnet Mask on the DIP Switch of Amplifier Unit
The response code (00: normal) and subnet mask (decimal, four octets of 3 digits each) are returned.
* The subnet mask is always 255.255.255.0 regardless of whether the DIP switch network settings are enabled or disabled.
Example 7: Checking IP Address in ROM
The response code (00: normal) and IP address in ROM (decimal, four octets of 3 digits each) are
returned.
* The above response is for when the IP address in ROM is 192.168.1.200.
Example 8: Checking the Subnet Mask in ROM
The response code (00: normal) and subnet mask (decimal, four octets of 3 digits each) are returned.
* The above response is for when the subnet mask in ROM is 255.255.255.0.
Command code
Parameter
type
CR
14120Dh
Command code
Parameter
type
CR
14130Dh
Command code
Parameter
type
CR
14140Dh
Command
Response
Response code Subnet mask on DIP switch CR
0 0 2552552550000Dh
First octet
Second octet
Third octet
Fourth octet
Command
Response
Response code IP address on DIP switch CR
0 0 1921680012000Dh
First octet
Second octet
Third octet
Fourth octet
Command
Response
Response code IP address on DIP switch CR
0 0 2552552550000Dh
First octet
Second octet
Third octet
Fourth octet
