CIDRW System
User’s Manual
SECTION 5
Window Configuration
SECTION 5
Browser Interface
A Amplifier Unit Information
B Network Setting Information
C Last Command Information
D Communications History Information
E Hardware Information
Item Description Comments
Model The product model number is displayed.
Firmware Version The firmware version is displayed.
MAC Address The MAC address is displayed.
DIP-SW "Enabled" is displayed if the Amplifier Unit is set to use the IP address
that is set on the DIP switch. "Disabled" is displayed if the Amplifier
Unit is set to use the IP address that is set in ROM.
Item Description Comments
Network Settings(DIP) If the Amplifier Unit is set to use the IP address that is set on the DIP
switch, this item is displayed in blue, and the IP address and subnet
mask of the Amplifier Unit are displayed.
If the Amplifier Unit is set
to use the IP address that
is set on the DIP switch,
this item is grayed out.
IP Address
Subnet Mask
Network Settings(ROM) If the Amplifier Unit is set to use the IP address that is set in ROM, this
item is displayed in blue, and the IP address and subnet mask of the
Amplifier Unit are displayed.
If the Amplifier Unit is set
to use the IP address that
is set in ROM, this item is
grayed out.
IP Address
Subnet Mask
Item Description Comments
Latest Communication The last command code that was executed and the last response code
that was returned by the Amplifier Unit are displayed.
Nothing is displayed if a
command has not been
executed since the
Amplifier Unit was
started.
Command Code
Response Code
Item Description Comments
Communication History History information on communications with the ID Tags is displayed.
Total Total number of communications
Success Total number of successful communications
Error Total number of failed communications
Item Description Comments
H/W Status Hardware information is displayed. "OK" is displayed for nor-
mal status.
Memory "Error" is displayed if a memory error was detected during the memory
check at startup.
Antenna "Error" is displayed if an error is detected in the CID Head that is con-
nected to the Amplifier Unit (or if a CID Head is not connected).
