CIDRW System
User’s Manual
SECTION 7
Characteristic Data According to Conditions of Use
SECTION 7
Appendix
83
• Parallel Mounting (RI-TRP-DR2B-30)
• READ
• WRITE
-250 -200 -150 -100 -50 0 50 100 150 200 250
0
50
100
150
200
250
Communications Area (READ)
Distance in Y direction (mm)
Distance in X direction (mm)
Measurement
point
-250 -200 -150 -100 -50 0 50 100 150 200 250
0
50
100
150
200
250
Communications Area (WRITE)
Distance in Y direction (mm)
Distance in X direction (mm)
Measurement
point
