Onan MicroLite 4000 Series

12-16
NOTE: OUTPUT VOLTAGE CAN BE ADJUSTED BY USE OF THE ADJUSTMENT POT ON THE FRONT OF
THE CONTROL PANEL. CLOCKWISE ROTATION WILL INCREASE THE VOLTAGE BY A MAXIMUM INCREASE OF 20 VAC.
FIGURE 12-15. VOLTAGE RECONNECTION DIAGRAM 612-1255 (MICROLITE, BEGIN SPEC F – 50 HZ/100 V)
