Onan MicroLite 4000 Series User Manual

5-3
M1723-1s
BATTERY
NEGATIVE (-)
CONNECTION
AC CONDUIT
CONNECTION
FUEL LINE
CONNECTION
BATTERY POSITIVE (+)
AND REMOTE CONTROL
HARNESS OPENING
DOOR
MOUNTING HOLES
SPEC A (4)
BEGIN SPEC B (6)
MOUNTING
HOLES
METAL
BARRIER
FIGURE 5-1. TYPICAL COMPARTMENT MOUNT INSTALLATION (SPEC A SHOWN)
BATTERY
NEGATIVE (-)
CONNECTION
AC CONDUIT
CONNEC
TION
DOOR
BATTERY POSITIVE (+)
AND REMOTE CONTROL
HARNESS OPENING
FUEL LINE
CONNEC
TION
SIDE
PANELS
COACH
FLOOR
METAL BARRIER REQUIRED
IF INSTALLED BELOW A
WOODEN FLOOR
M2001s
BOTTOM
RAIL
FIGURE 5-2. TYPICAL UNDER-FLOOR MOUNT INSTALLATION (BEGIN SPEC B SHOWN)

Onan MicroLite 4000 Series Specifications

General

Fuel Type	Gasoline
Frequency	60 Hz
Rated AC Output	4000 Watts
AC Voltage	120V
Rated AC Amperage	33.3A
Engine Type	OHV
Starting Method	Electric
Noise Level	68 dB at 23 ft
