6-2
ES2017s
STARTER MOTOR B1
IGNITION COIL T1
BATTERY CHARGE
RESISTOR R1
BRIDGE RECTIFIER CR1
START/STOP SWITCH S1
FUSE F1
CONTROL ASSEMBLY A1
SPARK PLUG E1
CIRCUIT BREAKER CB1
MAGNETO IGNITION G2
BRUSH BLOCK
START RELAY K1
VOLTAGE REGULATOR VR1
J1 CONNECTOR
P1 CONNECTOR
J4 CONNECTOR
P4 CONNECTOR
REMOTE CONTROL
CONNECTOR
STATOR CONNECTOR P5
FUEL PUMP E2
(FUEL SHUTOFF
SOLENOID ON
LPG MODELS)
STATOR CONNECTOR P6
FIGURE 6-1. COMPONENT LOCATIONS – GASOLINE-FUELED SPEC A MODELS
