F-3500 Insertion Electromagnetic Flow Meter Manual 02/18 - 0665-11 Page 8
SECTION 2.0: UNPACKING
ONICON insertion magnetic ow meters are packed and shipped in individual cartons. An optional
installation hardware kit INSTL1 or INSTL2, if ordered, will be packaged with each meter. All other
installation hardware and peripheral devices, including Btu meters and display modules, will be
packaged and shipped separately.
Please open all packages with care to prevent damage to their contents. Carefully inspect each item for
signs of damage in transit. The ow meter stem should be straight and free of blemishes or abrasions.
The sensor head should have a smooth continuous surface that is free of abrasions.
All ONICON products are shipped insured unless the customer specically requests otherwise. Please
notify the shipping company and ONICON immediately if any items are damaged in transit. Save all
packing material for inspection by the shipper.
2.1 CHECKING THAT YOU HAVE RECEIVED EVERYTHING
Standard Documentation
Enclosed with each meter is a comprehensive documentation package that includes the following
items:
Installation and Operation Guide
Flow Meter Certicate of Calibration
Please notify the ONICON if any of these documents are missing.
F-3500 Insertion Electromagnetic Flow Meter
Insertion depth collar and alignment tool. (For small pipe conguration meters.)
Optional INSTL1 or INSTL2 Installation Hardware Kit, if ordered
