11451 Belcher Road South, Largo, FL 33773 • USA • Tel +1 (727) 447-6140 • Fax +1 (727) 442-5699 • sales@onicon.com
F-3500 Insertion Electromagnetic Flow Meter Manual 02/18 - 0665-11 Page 9
SECTION 3.0: INSTALLATION, REMOVAL AND ADJUSTMENT
ONICON will be happy to assist with technical recommendations and to provide guidance by telephone
or e-mail. On-site eld engineering, installation and service is also available at additional cost.
3.1 INSTALLATION SITE SELECTION
Install the ow meter where it will be accessible for personnel to perform necessary periodic
maintenance. The clearance required for installation is typically 30-40” from the pipe wall to the
nearest obstruction above the valve assembly. This clearance dimension will increase with large
diameter pipes. The environment should be free of corrosive liquids/fumes, temperature extremes
and heavy vibration. The following diagrams should be used as a guide to the proper location for
installing the meter.
GENERAL PRACTICES:
1. For best results, install the ow meter in a straight run of pipe, free of bends, tees, valves,
transitions, and obstructions.
2. Straight run requirements vary based on the nature of the upstream obstruction.
See the table on the following page for guidelines in determining minimum up stream
straight run requirements based on the nature of the obstruction.
Note: Depending upon specic location details, more or less straight run may be
required to produce a satisfactory ow prole.
3. If there is insufcient straight run, allow 80% of the run upstream and 20% of the run
downstream. If the total length of straight run is less than 70% of the recommended length,
performance may seriously degrade, and consideration should be given to changing to the
series F-3000 Inline Electromagnetic Flow Meter.
WARNING
Insertion ow meters may be installed in pipes which are under high pressure. Accidents with
these systems can cause serious injury or death. Only persons experienced with high pressure
systems and related knowledge in the heating, cooling and uid metering elds should attempt
to install, adjust, or remove the ow meter. Please read all instructions before attempting to
insert or remove a ow meter.
How To Determine The Available Straight Pipe Diameters:
For each application, locate the longest straight, unobstructed section of pipe (no bends, tees, valves,
other insertion probes, size transitions). The longest straight pipe run in inches divided by nominal
pipe size in inches equals “diameters of straight pipe.” For closed loop applications, consider both
the supply and return lines as possible locations.
IMPORTANT NOTE
Always use the maximum available straight run. When more than the minimum required
straight run is available, place the meter such that the excess straight run is upstream of the
meter location.
