Register
Address
Description Register Type Register Type Comments
30009 Volume Rate - GPM Input Register Floating Point Register (1 of 2)
30010 Volume Rate - GPM Input Register Floating Point Register (2 of 2)
30011 Volume Rate - L/s Input Register Floating Point Register (1 of 2)
30012 Volume Rate - L/s Input Register Floating Point Register (2 of 2)
30013 Volume Rate - ft/min Input Register Floating Point Register (1 of 2)
30014 Volume Rate - ft/min Input Register Floating Point Register (2 of 2)
30015 Volume Rate - m/hr Input Register Floating Point Register (1 of 2)
30016 Volume Rate - m/hr Input Register Floating Point Register (2 of 2)
30017 Flow Temperature - °F Input Register Floating Point Register (1 of 2)
Temperature measured
by RTD in ow meter
30018 Flow Temperature - °F Input Register Floating Point Register (2 of 2)
Temperature measured
by RTD in ow meter
30019 Flow Temperature - °C Input Register Floating Point Register (1 of 2)
Temperature measured
by RTD in ow meter
30020 Flow Temperature - °C Input Register Floating Point Register (2 of 2)
Temperature measured
by RTD in ow meter
30029 Signal Strength (No units) Input Register Floating Point Register (1 of 2)
Range = 1-31; 1 is highest
signal strength; 31 is
lowest signal strength
30030 Signal Strength (No units) Input Register Floating Point Register (2 of 2)
Range = 1-31; 1 is highest
signal strength; 31 is
lowest signal strength
30031 Signal Quality (No units) Input Register Floating Point Register (1 of 2)
30032 Signal Quality (No units) Input Register Floating Point Register (2 of 2)
30033 Speed of Sound - ft/sec Input Register Floating Point Register (1 of 2)
Measured speed of sound
of the uid in the pipe
30034 Speed of Sound - ft/sec Input Register Floating Point Register (2 of 2)
Measured speed of sound
of the uid in the pipe
30035 Speed of Sound - m/sec Input Register Floating Point Register (1 of 2)
Measured speed of sound
of the uid in the pipe
30036 Speed of Sound - m/sec Input Register Floating Point Register (2 of 2)
Measured speed of sound
of the uid in the pipe
30157 Volume Total - Gal Input Register Floating Point Register (1 of 2)
30158 Volume Total - Gal Input Register Floating Point Register (2 of 2)
30159 Volume Total - Liters Input Register Floating Point Register (1 of 2)
30160 Volume Total - Liters Input Register Floating Point Register (2 of 2)
30161 Volume Total - ft Input Register Floating Point Register (1 of 2)
30162 Volume Total - ft Input Register Floating Point Register (2 of 2)
30163 Volume Total - m Input Register Floating Point Register (1 of 2)
30164 Volume Total - m Input Register Floating Point Register (2 of 2)
30181 Year to Date Volume Total - Gal Input Register Floating Point Register (1 of 2)
30182 Year to Date Volume Total - Gal Input Register Floating Point Register (2 of 2)
30183 Year to Date Volume Total - Liters Input Register Floating Point Register (1 of 2)
