F-4600 With LCD Flow Meter Manual 06/18 - 2020-3 / 35874 Page 32
30184 Year to Date Volume Total - Liters Input Register Floating Point Register (2 of 2)
30185 Year to Date Volume Total - ft
3
Input Register Floating Point Register (1 of 2)
30186 Year to Date Volume Total - ft
3
Input Register Floating Point Register (2 of 2)
30187 Year to Date Volume Total - m
3
Input Register Floating Point Register (1 of 2)
30188 Year to Date Volume Total - m
3
Input Register Floating Point Register (2 of 2)
30205 Previous Year Volume Total - Gal Input Register Floating Point Register (1 of 2)
30206 Previous Year Volume Total - Gal Input Register Floating Point Register (2 of 2)
30207 Previous Year Volume Total - Liters Input Register Floating Point Register (1 of 2)
30208 Previous Year Volume Total - Liters Input Register Floating Point Register (2 of 2)
30209 Previous Year Volume Total - ft
3
Input Register Floating Point Register (1 of 2)
30210 Previous Year Volume Total - ft
3
Input Register Floating Point Register (2 of 2)
30211 Previous Year Volume Total - m
3
Input Register Floating Point Register (1 of 2)
30212 Previous Year Volume Total - m
3
Input Register Floating Point Register (2 of 2)
30229 User Dened Volume Total - Gal Input Register Floating Point Register (1 of 2)
30230 User Dened Volume Total - Gal Input Register Floating Point Register (2 of 2)
30231 User Dened Volume Total - Liters Input Register Floating Point Register (1 of 2)
30233 User Dened Volume Total - ft
3
Input Register Floating Point Register (1 of 2)
30234 User Dened Volume Total - ft Input Register Floating Point Register (2 of 2)
30235 User Dened Volume Total - m Input Register Floating Point Register (1 of 2)
30236 User Dened Volume Total - m Input Register Floating Point Register (2 of 2)
30253 Auxiliary Pulse Input Count- Input 1 Input Register Floating Point Register (1 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30254 Auxiliary Pulse Input Count- Input 1 Input Register Floating Point Register (2 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30255 Auxiliary Pulse Input Count- Input 2 Input Register Floating Point Register (1 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30256 Auxiliary Pulse Input Count- Input 2 Input Register Floating Point Register (2 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30257 Auxiliary Pulse Input Count- Input 3 Input Register Floating Point Register (1 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30258 Auxiliary Pulse Input Count- Input 3 Input Register Floating Point Register (2 of 2)
Unitless count. Value
is representative of the
total number of pulses
received on input.
30259 Run Hours Input Register Floating Point Register (1 of 2)
30260 Run Hours Input Register Floating Point Register (2 of 2)
30261 Meter Status Input Register Short Integer Register
0 Normal
7 Low Signal Quality
8 Comm error
9 Low Supply Voltage
10 System Fault
