Onkyo TX-LR552

60
SN 29343748
I0407-1
(C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved.
http://www.onkyo.com/
HOMEPAGE
* 2 9 3 4 3 7 4 8 *
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.onkyousa.com
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.onkyo.net
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Power output: Front L/R 65 W + 65 W
Center 65 W
Surround L/R 65 W + 65 W
Surround back L/R 65 W
(6
Ω , 1 kHz, FTC)
Dynamic power: 40 W + 40 W (8 Ω , front)
THD (total harmonic
distortion): FTC 5.0% (rated power)
Damping factor: 75 (front, 1 kHz, 8
Ω )
Input sensitivity and
impedance: 200 mV/47 k
Ω (AUX)
Output level and
impedance: 200 mV/470
Ω (REC OUT)
Frequency response: 10 Hz–60 kHz/+1.5 dB, –3 dB (AUX)
Tone control: ±12 dB, 100 Hz (BASS)
±12 dB, 20,000 Hz (TREBLE)
S/N ratio (Direct mode): 100 dB (AUX, IHF-A)
Speaker impedance: 6
Ω – 16 Ω
Input sensitivity, output
level and impedance:
1.0 Vp-p/75 Ω (component and S-Video Y)
0.7 Vp-p/75 Ω (component P B /C B , P R /C R )
0.28 Vp-p/75
Ω (S-Video C)
1.0 Vp-p/75
Ω (composite)
Component video
frequency response: 5 Hz–50 MHz
Tuning frequency range: 87.5–107.9 MHz
Usable sensitivity: Stereo 17.2 dBf, 2.0 µV (75
Ω IHF)
Mono 11.2 dBf, 1.0 µV (75
Ω IHF)
S/N ratio: Stereo 67 dB (IHF-A)
Mono 70 dB (IHF-A)
Frequency response: 30 Hz–15 kHz/+1 dB, –1 dB
Stereo separation: 45 dB at 1 kHz
Tuning frequency range: 530–1710 kHz
Usable sensitivity: 30 µV
S/N ratio: 40 dB
Power supply: AC 120 V, 60 Hz
Power consumption: 110 W
Standby power
consumption: 1.70 W
Dimensions
(W x H x D): 17-1/8" x 3-9/16" x 14-7/16"
(435 x 91 x 367 mm)
Weight: 14.3 lbs. (6.5 kg)
Component video inputs:2 (COMPONENT VIDEO 1, 2)
S-Video inputs: 3 (DVD, VIDEO 1, VIDEO 2)
Video inputs: 3 (DVD, VIDEO 1, VIDEO 2)
Component video
outputs: 1 (MONITOR)
S-Video outputs: 2 (MONITOR, VIDEO 1)
Video outputs: 2 (MONITOR, VIDEO 1)
Digital inputs: 3 (Optical 1, 2, Coaxial)
Analog inputs: 5 (AUX, VIDEO 1, VIDEO 2, TV, DVD)
Multichannel analog
inputs: 1
Analog outputs: 1 (VIDEO 1)
Subwoofer pre out: 1
Speaker outputs: 6
Phones: 1
