Onkyo TX-SR605

93
Specifications
Amplifier Section
Video Section
Tuner Section (TX-SR605 only)
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels: 90 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08%
105/110 watts minimum continuous
power per channel, 8 ohm loads,
2 channels driven at 1 kHz, with a
maximum total harmonic distortion of
0.7/0.9%
110 watts minimum continuous power
per channel, 6 ohm loads, 2 channels
driven at 1 kHz with a maximum total
harmonic distortion of 0.1%
Rated Output Power (IEC)
7 ch
u 140 W at 6 ohms, 1 kHz, 1 ch
driven
Maximum Output Power (JEITA)
7 ch u 175 W at 6 ohms, 1 kHz, 1 ch
driven
Dynamic Power 210 W + 210 W (3 :, Front)
180 W + 180 W (4 :, Front)
110 W + 110 W (8 :, Front)
THD (Total Harmonic Distortion)
0.08% (Power Rated)
0.08% (1 kHz, 1 W)
Damping Factor 60 (Front, 1 kHz, 8 :)
Input Sensitivity and Impedance
200 mV/47 k: (LINE)
Output Level and Impedance
200 mV/470 : (REC OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance North American: 6 : - 16 :
Others: 4 : - or 6 : - 16 :
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 : (Component and S-Video Y)
0.7 Vp-p/75 : (Component PB/CB, PR/CR)
0.28 Vp-p/75 : (S-Video C)
1 Vp-p/75 : (Composite)
Component Video Frequency Response
5 Hz - 50 MHz - 3 dB
FM Tuning Frequency Range
North American: 87.5 MHz - 107.9 MHz
Others: 87.5 MHz - 108.0 MHz
AM Tuning Frequency Range
North American: 530 kHz - 1710 kHz
European: 522 kHz - 1611 kHz
Others: 522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply North American: AC 120 V, 60 Hz
European: AC 230 V, 50 Hz
Others: AC 120/220 - 240 V, 50/60 Hz
AC 220 V, 50/60 Hz
Power Consumption North American: 6.5 A
Others: 630 W
Dimensions (W u H u D)
435 u 174 u 377 mm
17-1/8" u 6-7/8" u 14-13/16"
Weight North American: 11.4 kg (25.1 lbs.)
Australian: 11.6 kg (25.6 lbs.)
Others: 11.5 kg (25.4 lbs.)
HDMI IN1, IN2
Component IN1, IN2, IN3
S-Video DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV,
AUX
HDMI OUT
Component OUT
S-Video MONITOR OUT, VCR/DVR
Composite MONITOR OUT, VCR/DVR
Digital Inputs Optical: 3 (1 on Front Panel)
Coaxial: 2
Analog Inputs DVD (MULTICHANNEL), VCR/DVR,
CBL/SAT, GAME/TV, AUX, TAPE, CD
Multichannel Inputs 7.1
Analog Outputs TAPE, VCR/DVR, ZONE2
Subwoofer Pre Output 1
Speaker Outputs L, R, C, SL, SR, SBL, SBR,
ZONE2 (L/R)
Phones 1
