Installation
22
which one is connected in the EM060L emitters, and the second is projected inter-
nally in the RE060AUTOL unit.
8. Make all the tubing connections according to the tubing drawing, see drawing no. 9
in section 9. Connect the purge air.
5.5.1 Electrical connections
Attach the flex tube to the bottom of the receiver and make all the electrical connections.
The cables are labeled with corresponding numbers in the receiver. See the electrical con-
nections drawing no. 7 in section 9.
5.5.2 Fiber optic connections
Make all the fiber optic connections according to the optical fibers drawing, see drawing
no. 8 in section 9.
