Opsis LD500 - The Receiver RE060 L

Emitters and receivers
3
1.1.3 The receiver RE060L
The RE060L unit contains a fibre holder and a mirror. The optical components are adjust-
able for the optimisation of the calibration light.
Main parts of the receiver RE060L
1 1 ½“ thread
2 Purged air inlet
3 Optical fibre inlet
4 Power inlet (± 12 V)
5Detector
6Mirror
7 A/D converter
Note: The coating on the mirror is very sensitive. It must not be touched or cleaned with
liquids.
F
igure 1.3. The receiver RE060L.
1
2
34
5
6
7
