Appendix: ER060AUTOL setup
iii
3. Press [F1] Cylinder/CU007 settings.
4. Press [F2] to switch between digital and serial. Choose serial.
5. Press [F3] Com port setup. In the menu the following information is entered:
• Com port
•IRQ
• The baud rate is set to 9600.
The rest of the settings are default. Press [Esc] to leave the menu.
6. Set cylinder 1 to 7 to automatic control in the Man/Auto field.
7. Place the courser in the Open/Close field for valve 1. By pressing the [Enter],
valve no. 1 in the CU007 will open and close. When the valve is opened the red
LED on top of the valve is lit.
8. Pressing [F1] will manually move the calibration mirror in the RE060AUTOL in
and out of the measurement path.
Note: The com port and IRQ must correspond to the settings stated by the label on the
back side of the analyzer.
