Assistant Service Manual
OPTIKON 2000
Code 121008S 4-2 Rev. D
1) I/A SYSTEM
Disposable I/A tubing set and dual pump cassette.
2) LCD TOUCH-SCREEN DISPLAY
By means of this LCD touch-screen the user can
- activate the proper functions
- setup all parameters
- read all actual and preset values
- read warnings and error messages
- program the equipment and footswitch
3) ELECTRIC IV POLE
4) DIATHERMY SOCKET
Bipolar diathermy handpiece cable fits into this socket.
5) U/S (Phaco) SOCKET
Phaco handpiece connector plugs into this socket.
6) SCISS (Micro Scissors) SOCKET
The activation line of the semi-disposable microscissors handpiece plugs into
this socket .
7) AIR SOCKET
This socket is provided to accept a sterilizing filter and a low pressure air
supply tubing assembly.
8) VIT SOCKET
The activation line of the vitrectomy handpiece plugs into this socket
9) SIL (Silicone injection) SOCKET
Pressure delivery tube for silicone oil injection fits into this socket
10) OPTICAL FIBER SOCKET “Light 1”
11) OPTICAL FIBER SOCKET “Light 2”
Optical fiber connectors plug into these sockets. The surgeon may plug up to
two fibers simultaneously in each connector.
12) TRAY FOR SURGICAL INSTRUMENTS
