Assistant Service Manual
OPTIKON 2000
Code 121008S 5-8 Rev. D
1) TOUCH SCREEN CONTROLLER BOARD (391160000)
This board provides interface between the touch screen and the PS2 input
of the PC board.
2) PC BOARD
This board is an embedded PC system that includes all the peripherals
(RS232, USB, LPT, VGA, PS2, etc.) which are necessary for the GUI.
3) STEP UP BOARD FOR TFT ILLUMINATION (391150000)
This boards contains a step up voltage converter that elevates the +12Vdc
to a voltage that can drive the dual neon lamp retro illumination system of
the TFT LCD.
4) SOLID STATE HARD DISK (DOM) (391170000)
The solid state HD contains all the Graphic User Interface software; this
includes the operating system, the graphic control software, the user
settings (programs) and other configuration parameters.
5) CONNECTOR TO THE TOUCH SCREEN
This connector plugs in the flat cable of the touch screen which is attached
to the monitor frame.
6) 12.1” TFT DISPLAY 800x600 (616025000)
