DV11 / DVD100 / U2 / U3
2-1
Chapter 2
Disassembly Process
2-1 Equipment Needed & Product Overview
2. Hex Sleeves 5mm
3. Hex Sleeves 8mm
5. Projector
* Before you start: This process is protective level II. Operators should wear electrostatic chains.
* Note: - If you need to replace the main board, you have to get into service mode and record the
lamp usage hour. please refer to section 2-25.
- As the process of DVD100 / U2 / U3 disassembling is the same as DV11, we take
DV11 for example here.
To Next Page
