DV11 / DVD100 / U2 / U3
III
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-2
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover 2-2
Disassemble Lamp Module 2-2
Disassemble Top Cover Module 2-3
Disassemble Keypad Board 2-4
Disassemble Speaker Module 2-4
Disassemble Front & Back Cover Module 2-5
Disassemble EMI Front Cover 2-5
Disassemble DVD Module 2-6
Disassemble MB Module 2-8
Disassemble Air Cut Module 2-9
Disassemble System Fan Module 2-9
Disassemble Lamp Driver Module 2-10
Disassemble LVPS Module 2-11
Disassemble Power Bracket 2-11
Disassemble Bottom Cover Module 2-12
Disassemble Engine Module 2-12
Disassemble Bottom Base Plate Module 2-13
Disassemble Engine & Color Wheel 2-13
Disassemble Zoom Ring & Focus Ring 2-14
Disassemble DMD Chip 2-15
