Optoma DV11 - Disassemble Bottom Base Plate Module; Disassemble Engine & Color Wheel

DV11 / DVD100 / U2 / U3  2-13
2-18 Disassemble Bottom
Base Plate Module
1. Unscrew 3 screws on the blower fan
2. Unscrew 2 screws on the limit switch
2-19 Disassemble Engine &
color wheel
1. Unscrew 1 screw on the thermal switch
2. Unscrew 1 screw on the color wheel
