DV11 / DVD100 / U2 / U3
4-10
3. Full On/Full Off Contrast
Procedure - Full white pattern & full black pattern
- Use CL100 to measure brightness values of full
white pattern P5 & full black pattern B5 ( see im-
age: full white)
- Follow Contrast formula to calculate contrast
values.
P5/B5
Criteria • 1300:1• 1300:1 1300:1
4. Uniformity
Procedure - Full white pattern
- Use CL100 to measure brightness values of
- Follow the Uniformity formula to calculate
average values.
P5
4-9 Others
1. Functional Inspection
Keypad button - All keypad buttons must operate
smoothly.
General - All OSD functions must be
Full black pattern
To Next Page
