Optoma EP783 - Table of Contents

EP783/EP783S/EP783L/OPX5000/TX783L/TX783S
Condential
IV
Table of Content
Chapter 1 Introduction
Highlight 1-1
Compatible Mode 1-3
Chapter 2 Disassembly Process
Equipment Needed & Product Overview 2-1
Disassemble Lamp Cover and Lamp Module 2-2
Disassemble Inside Ring and Outside Ring 2-3
Disassemble Top Cover Module and FPC Cable 2-3
Disassemble Keypad Module and Top Cover 2-4
Disassemble IR Sensor Board 2-5
Disassemble Keypad Board 2-5
Disassemble I/O Cover 2-6
Disassemble I/O Shielding 2-6
Disassemble Top Shielding 2-7
Disassemble Main Board Module 2-7
Disassemble Wireless Board 2-9
Disassemble Wireless House 2-10
Disassemble Blower Module 2-10
Disassemble Sheet Metal 2-11
Disassemble Lamp Driver Module 2-10
Disassemble Air Duct 2-12
Disassemble Left Cover and IR Sensor 2-13
Disassemble Handle Bar 2-14
Disassemble Right Cover Module and Plastic-net 2-14
Disassemble Fan Module 2-15
